GV-FD2500 2MP H.264 Super Low Lux WDR IR Fixed IP Dome



介绍
GV-FD2500 是一款安装方便的室内型摄像机,三轴设计使得摄像机的安装调试非常灵活。配备的超低照度CMOS传感器可以在黑暗的环境下为您提供彩色的监控画面。可以安装在各种类型的地点比如:吊顶、墙面或者柱子上,相机配件可选。


  • 特征
  • 尺寸
  • 镜头
  • 附件
  • 包装清单

  • 1/2.8" 超低照度逐行扫描 CMOS
  • 最低照度0.02lux
  • 双码流H.264和MJPEG
  • 1920 x 1080分辨率高达30帧
  • 三轴机械调节(水平/垂直/旋转)
  • 变焦镜头
  • 智能红外
  • 红外照射最远30米
  • 双向语音
  • 一组传感器输入及一组传感器输出
  • 支持电视输出
  • 支持Micro SD / SDHC存储卡插槽
  • DC 12V / AC 24V / PoE
  • 宽动态
  • 3D数字降噪
  • 除雾
  • 移动侦测
  • 入侵报警
  • 隐私遮罩
  • 日夜功能(红外滤波片)
  • IP 地址过滤
  • 支持iPhone, iPad, Android 和 3GPP
  • 网页界面支持31国语言
  • ONVIF(Profile s)标准
遮挡报警
遮挡 焦点变化 场景变化


点击大图

For required accessories of each installation, click the corresponding illustration under the Mounts section.
Model No. Name Details
GV-Mount100 Straight Tube and Junction Box Kit Dimensions:
Weight:
GV-Mount101 Straight Tube Kit Dimensions:
Weight:
GV-Mount200 Wall Pendant Tube Dimensions:
Weight:
GV-Mount203 Wall Pendant Tube and Junction Box Kit Dimensions:
Weight:
GV-Mount300 Convex Corner Adapter Kit Dimensions:
Weight:
GV-Mount310 Concave Corner Adapter Kit Dimensions:
Weight:
GV-Mount400 Pole Mount Bracket Kit
()
Bracket:
Weight:
Steel Strap Diameter:
GV-Mount410 Pole Mount Bracket Kit
()
Bracket:
Weight:
Steel Strap Diameter:
GV-Mount702 Extension Tube Four options are available.
Dimensions:
Weight:
GV-Mount900 Wall Mount Bracket Dimensions:
Weight:
GV-Mount902 GV-FD Series Dome Housing Dimensions:
Weight:
GV-Mount909 Wall Mount Bracket Dimensions:
Weight:
GV-Mount913 Power Box Mount Bracket Dimensions:
Weight:
  Smoked Cover Dimensions: ø 103.7 x 55 mm (4.08 x 2.16")
Weight: 30g (0.07 lbs)
Vandal Resistance: IK7
GV-PA191 Power over Ethernet (PoE) Adapter The GV-PA191 is a Power over Ethernet (PoE) adapter designed to provide power to the IP device through a single Ethernet cable.
GV-Relay V2 The GV-Relay V2 is designed to expand the voltage load of GV IP devices. It provides 4 relay outputs, and each can be set as normally open (NO) or normally closed (NC) independently as per your requirement.
GV-POE Switch The GV-POE Switch is designed to provide power along with network connection for IP devices. The GV-POE Switch is available in various models with different numbers and types of ports.
Power Adapter Power adapters are available in 5 regions: Australia, Brazil, Europe, U.K and U.S.

  • 固定网络半球
  • 梅花扳手
  • 固定板
  • 短膨胀管 x 3
  • 螺丝 x 3
  • 固定螺丝 x 3
  • TV-输出线
  • 标签
  • GV-IPCAM H.264 安装说明书
  • GV-IPCAM H.264软件光盘
  • GV-NVR 安装说明书
  • GV-NVR 软件光盘
注:
1.请用柔软干净的布清理外罩,以免刮伤外罩。
2. 规格如有更改,恕不另行通知。
